CNMC58 Type Hydraulic-driven Polyurea Spray Machine has wide scope of applications.
1. Insulation & Coating: external wall insulation, internal wall insulation, roof, cold storage, ship cabin, cargo containers,trucks, refrigerated trucks,tank, etc.
2. Casting: solar water heaters,tank insulation, cabin, insulation board, security doors, refrigerators, pipes, road construction, packaging, road construction, wall insulation, etc.
The advantage:
1. double cylinder supercharged unit, easily providing adequate working pressure;
2. with small volume, light weight, low failure rate, simple operation, easy mobility;
3. adopting the most advanced ventilation method, guarantee equipment working stability to the maximum;
4. minimizing spraying congestion with 4-layers-feedstock device;
5. multi-leakage protection system to protect the safety of the operator;
6. equipped with emergency switch system, help operator deal with emergencies rapidly;
7. digital counting system can understand original consumption timely;
8. reliable & powerful 380v heating system enables rapid warming of raw materials to the best state, making sure it works great in cold condition;
9. humanized design with equipment operation panel, super easy to get the hang of it;
10. lifting pump adopts big change ratio method, it can easily feed raw materials high viscosity even in winter.
11. the latest spraying gun has great features like small volume, light weight, low failure rate, etc;
Technical Parameters:
Power source:3 phase 4 wires 380V 50Hz Heating power: 20KW
Driven mode: hydraulic Air source: 0.5~0.8 MPa ≥0.5m3/min
Raw output: 2~12 kg/min Maximum output pressure: 36Mpa
AB material output ratio: AB 1:1
